Internally Externally Heated Dryer

Name: Internally Externally Heated Dryer
Brand: ADON EQUIPMENTS PRIVATE LIMITED
Price: 1000000 INR
Availability: InStock

Price 1000000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Internally Externally Heated Dryer Specification

Basket Volume
100 Liters

Drive
Electric Motor Driven

Dimension (L*W*H)
1800 x 1200 x 2100 mm

Inlet Temperature
Up to 45C

Power Output
3 kW

Temperature
Up to 120C

Power Consumption
3 kW

Inlet Oil Content
<0.01 ppm

Power Input
3.5 kW

Heating Power
2.5 kW per heater

Pressure
7 bar (max)

Power Mode
Automatic / Manual

Fan Capacity
2500 m3/h

Basket Diameter
500 mm

Air Flow
200 Nm3/hr per tower

Place of Origin
India

Noise Level
Below 70 dB

Usage
Industrial

Power Source
Electric

Lubrication Type
Oil-Free / Dry Type

Product Type
Internally Externally Heated Dryer

Voltage
415 V AC, 3 Phase

Color
Blue

Warranty
1 Year

Finishing
Corrosion Resistant Coating

Regeneration Method
Internal / External Electrically Heated

Control Panel
Digital Display, PLC Controlled

Piping Material
Seamless Stainless Steel

Cycle Time
30 mins (adjustable)

Drying Medium
Regenerative Desiccant

Installation Type
Skid Mounted

Operating Ambient Temp
5C - 50C

Applicable Industries
Pharmaceutical, Chemical, Food Processing, Industrial

Moisture Removal
Up to -40C Dew Point

Internally Externally Heated Dryer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Others

Supply Ability
10 Units Per Month

Delivery Time
10 Days

Main Domestic Market
Gujarat

About Internally Externally Heated Dryer

This is an advance version of the heatless dryer where purge air loss is very low due to regeneration is achieved by dry air at low pressure and at high temperature.

Dew point up to (-) 60 Deg C (atm) can be achieved.
Longer Life of Desiccant
Microprocessor based Controller with Display.
No need of Cooling Water

Reliable Moisture Control for Critical Applications

Achieve optimal drying with advanced regenerative desiccant technology, ensuring up to -40C dew point performance. The system is designed for consistency and reliability in sensitive sectors such as pharmaceuticals and food processing, where moisture control is crucial for quality and compliance.

Smart Monitoring and Hands-Free Operation

The digital PLC control panel provides intuitive monitoring and easy adjustments with real-time data, reducing operator intervention. With automatic and manual modes, users can customize cycle times and drying parameters effortlessly, resulting in enhanced productivity and minimal downtime.

Durable, Safe and Easy to Install

Constructed with seamless stainless steel piping and finished with a corrosion-resistant coating, this dryer promises longevity even in challenging industrial settings. Skid mounting simplifies installation, and a compact footprint fits easily into existing plant layouts, while noise levels remain below 70 dB for a safer, more comfortable work environment.

FAQ's of Internally Externally Heated Dryer:

Q: How does the dryer achieve moisture removal up to -40C dew point?

A: This system uses regenerative desiccant technology, which draws out moisture from compressed air via high-performance desiccant materials. Internal or external electric heaters regenerate the desiccant, ensuring consistent low dew points as required by demanding applications.

Q: What industries can benefit from using this internally and externally heated dryer?

A: Industries such as pharmaceutical, chemical, food processing, and general industrial manufacturing can benefit from its precise moisture removal, oil-free operation, and compliance with stringent quality standards.

Q: When should I use automatic versus manual power mode?

A: Automatic mode is ideal for standard operations requiring minimal intervention, ensuring efficiency and consistency. Manual mode can be selected for process customization, maintenance, or unique drying requirements, giving operators full control.

Q: Where can this dryer be installed within a facility?

A: With its skid-mounted design and compact dimensions (1800 x 1200 x 2100 mm), the dryer can be easily installed in production areas, utility rooms, or adjacent to primary machinery, provided there is access to power and safe ventilation.

Q: What makes the drying process efficient in this equipment?

A: The combination of regenerative desiccant, electrical heaters, and a digitally controlled PLC system enables quick cycle changes (30 minutes, adjustable), stable air flow (200 Nm3/hr per tower), and reliable temperature control up to 120C.

Q: How is maintenance and monitoring simplified for users?

A: Digital display and PLC controls provide real-time system status and alerts, while the oil-free, dry lubrication reduces maintenance needs. Corrosion-resistant construction also enhances longevity and lessens routine upkeep demands.

Q: What advantages does seamless stainless steel piping provide?

A: Seamless stainless steel piping ensures higher integrity, prevents leaks, and offers resistance against corrosion and contamination, making it suitable for sensitive environments and high purity requirements.
